1. Fiber optics, quadruple spray ports, quick-stop function, anti-retraction valve.
2. It’s brighter with a larger light pattern than the traditional power optic systems.
3. The drive air rotates the miniature generator. The electricity generated illuminates the LED that is optimally positioned on the face of the handpiece,
YAYIDA Professional YAYIDA Dental Push Button Fiber Optic Handpiece Superior Turbine Concentricity Contribute to Accurate Tooth Surface Preparati manufacturers,Fast Delivery
YAYIDA Customized YAYIDA Dental Push Button Fiber Optic Handpiece Superior Turbine dental handpiece supplier manufacturers From China,Professional service
providing daylight bright illumination.
4. It’s so efficient there is no loss of air pressure or torque, and the four coolant water ports provide the desired coolant spray pattern.
Description
1. LED light provides superior illumination.
2. Color correction similar to daylight.
3. Covers a larger area compared to conventional fiber optic light patterns.
4. Opening cartridge
5. High power with perfect head size to performance ratio.
6.Anti-retraction function avoiding cross-infection.
7. Quattro water spray, better atomization.
Parameter
| Drive air pressure | 200-300kpa(2.0-3.0bar) | Drive air pressure recommended | 250kpa(2.5bar) |
| Return air pressure | <0.5 bar (50kpa) | Spray water pressure | 220-300kpa(2.2-3.0 bar) |
| Spray air pressure | 220-300kpa(2.2-3.0bar) | Air consumption | ＜80Nl/min |
| Amount of spray air | 1.5Nl/min (at 2.0 bar) | Cooling airflow | 5 to 40Nl/min (at 3.0 bar) |
| Bur applicable | Φ1.59mm~Φ1.6mm | Noise | ≤68dB |
| Bearing | Ceramic bearing | Rotation speed | 330000-420000r/min |
| Chuck type | Push-button | Light intensity | ≥7,000 LUX |
| Holes | 4/6 hole for choose | Disinfection | autoclavable to 135 ℃ |
| Available connection | for multiflex coupling | Delivery Time | Usually 2–5 days Fast Delivery by DHL, FedEx |
| OEM available | YES | Customized | YES |
Display
