Description
1. The piezoelectric working way ensures that the machine always works on steady power, has high efficiency, and generates little heat.
2. Digitally controlled, automatic frequency tracking ensures that the machine always works on the best frequency and more steadily.
3. The design of automatic amplitude compensation function reduces patients’ discomfort.
4. The scaler tip is made of stainless steel. The atomized spraying design forms the cavitations, and in conditions of water, it will form oxygenated water to release the new eco-pure oxygen, which can efficiently inhibit periodontal anaerobic bacteria against periodontal diseases.
5. Ergonomic design of the handpiece makes it easy for long time use.
6. Cable of the handpiece is made of imported silica gel tube, soft and durable.
7. Axis of the handpiece is made of high-quality titanium alloy, strong and durable.
8. Wide range power offers more convenience for operation.
9. Beautiful appearance, small and light, exquisite craft.
Parameter
| Model | AYD-B5L | Adapter Input | 100-240V~ 50/60Hz 0.7A-0.4A |
| Main unit input | 30V 1.2A | Main unit fuse | 250V/T 1.6AL |
| Output power | 3W~ 20W | Output primary tip vibration excursion | ≤200μm |
| Output tip vibration frequency | 28kHz±3kHz | Output half-excursion force | <2N |
| Water pressure | 0.1MPa~0.5MPa (1bar~5bar) | 5 Pcs Tips | T1*2, T2*1, T3*1, T4*1 |
| Weight of the main unit | 0.55kg | Weight of adapter | 0.34kg |
| Operating mode | Continuous operation | Electric shock protection type | Class II |
| Classification 93/42/EEC | Class II a | Degree of protection against electric shock | B |
| Degree of protection against harmful ingress of water | Ordinary equipment(IPX0), Foot switch(IPX1) | Degree of safety of application in the presence of a Flammable Anesthetic Mixture with air or with Oxygen or Nitrous Oxide | Equipment not suitable for being used in the presence of a flammable anesthetic mixture with air or with oxygen or nitrous oxide |
